Product Application:
| Baghouse dust collector is a dry dust filter. It is suitable for capturing fine, dry, non-fibrous dust. The filter bag is made of woven filter cloth or non-woven felt. The dust filter is filtered by the filtering effect of the fiber fabric. When the dust-containing gas enters the bag filter, the particles with large particles and large specific gravity are due to gravity. The effect settles down and falls into the ash hopper. When the gas containing fine dust passes through the filter material, the dust is retained and the gas is purified. |
Product model table:
The company's products support customization, welcome to consult us.
| model | YT-01MC24 | YT-01MC32 | YT-01MC36 | YT-01MC48 | YT-01MC64 | YT-01MC72 |
| Size (mm) | 1420*1430*2800 | 1550*860*2800 | 1200*1200*2800 | 1550*1200*2800 | 1540*1540*4400 | 1710*1540*4400 |
| Weight (kg) | 1133 | 1340 | 1485 | 1495 | 1730 | 1950 |
| Filtration area | 18 | 24 | 27 | 36 | 45 | 54 |
| air volume (m³/h) | 2160-4300 | 2800-3150 | 3250-6480 | 3984-7281 | 4012-7419 | 5715-10562 |
| pulse valves | 4 | 4 | 6 | 6 | 8 | 8 |
| filter bags | 24 | 32 | 36 | 48 | 64 | 72 |
| power | 2.2kw | 3kw | 3kw | 4kw | 5.5-7.5kw | 7.5kw |
| noise | ≤50db | ≤50db | ≤50db | ≤50db | ≤50db | ≤50db |
| model | YT-01MC96 | YT-01MC100 | YT-01MC120 | YT-01MC160 | YT-01MC200 |
| Size (mm) | 2220*1540*4400 | 2280*2280*4400 | 2420*2080*4600 | 3500*2080*4600 | 4180*2080*4600 |
| Weight (kg) | 2400 | 2550 | 2870 | 3200 | 3600 |
| Filtration area | 72 | 85 | 90 | 130 | 160 |
| air volume m³/h | 5715-10562 | 7328-14455 | 7328-14455 | 8528-18455 | 9928-20455 |
| pulse valves | 12 | 10 | 12 | 16 | 20 |
| filter bags | 96 | 100 | 120 | 160 | 200 |
| power | 11kw | 11kw | 11kw | 18.5kw | 12kw |
| noise | ≤72db | ≤72db | ≤72db | ≤72db | ≤72db |
YITE Environmentally friendly, giving you a green space.
For your health, we are working hard.
Main features of the product:
1) The dust removal efficiency is high, generally above 99%, and the dust concentration of the outlet gas of the dust collector is within tens of milligrams per cubic meter, which has a higher classification efficiency for fine dust of submicron particle size. 2)The air volume can be processed in a wide range, ranging from a small number of m3 in 1 minute to a tens of thousands of m3 in a large one, which can be used for dust removal in industrial furnaces and kiln to reduce emissions of atmospheric pollutants. 3) When high temperature resistant filter materials such as glass fiber, polytetrafluoroethylene and P84 are used, it can be operated at a high temperature of 200 ° C or higher. 4) It is not sensitive to the characteristics of dust and is not affected by dust and electrical resistance. 5) The machine can be assembled flexibly and widely used. Safe and efficient. |
FAQ:
Q1.Are you a factory and trading company?
A: We are a factory. Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Q3. Can you suggest me a suitable type?
A: Certainly, Once you give me the keyword. The most suitable size will be choose to meet your need. Q4. How about your delivery time?
A: Generally, it will take 7-30 days after receiving your advance payment. The specific delivery time depends on the items , transportation ways and the quantity of your order. Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures. Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery. Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from. |
